Description
| Gain (user-selectable) | 0dB, 9dB and 18dB | ||
| Headphone outputs | XLR 3-pin XLR 4-pin 6.3mm 6.3mmBAL 4.4mm SE 3.5mm |
Balanced separate left and right sockets Balanced stereo SE stereo positive phase SE stereo inverted phaseBuilt-in IEMatch -18dB Built-in IEMatch -14dB |
|
| Frequency Response | 0.5Hz to 500kHz(-3dB) | ||
| THD & N | Balanced | Solid-State Tube Tube+ |
0.0015% 0.002% 0.012% |
| Single- Ended | Solid-State Tube Tube+ |
0.005% 0.005% 0.2% |
|
| SNR | Balanced Single-Ended |
>147dB(A) > 137dB(A) |
|
| Output Power | Balanced Single-Ended |
>14,000mW (@ 16) >4,800mW (@ 16) |
|
| Output Voltage | Balanced Single-Ended |
>23V (@ 600) >11.5v (@ 600) |
|
| Input voltage (Pro iDSD Signature) | DC 9V/6.7A – 18V/3.35A | ||
| Input voltage (iPower Elite) | AC 85 – 265V, 50/60Hz | ||
| Power consumption | < 22W idle, 50W max | ||
| Dimensions | 213 x 193 x 63 mm 6.2″ x 3.9″ x 1.4″ |
||
| Net weight | 1.93 kg 4.3 Ibs |
