Description
DESIGN
4-driver, 3-way bass reflex, floorstanding
FREQUENCY RESPONSE ON-AXIS
±3dB from 43 Hz – 25 kHz
HIGH FREQUENCY DRIVER
1” (25mm) X-PAL™ dome, ferro-fluid damped / cooled, Perforated Phase-Aligning Tweeter (PPA™) Lens
MIDRANGE FREQUENCY DRIVER
6-1/2” (165mm) Surround with Carbon-Infused polypropylene cone. Perforated Phase-Aligning (PPA™) Lens
LOW FREQUENCY DRIVER
Two 6-1/2” (165mm) ART™ Surround Carbon-Infused polypropylene cones
SENSITIVITY ROOM / ANECHOIC
92 dB / 89 dB
IMPEDANCE
Compatible with 8 ohms
FINISHES
Gloss Black, Gloss White
WEIGHT
53.4 lbs. (24.2 kg)
DIMENSIONS HXWXD
41.5″ × 9.125 × 13.75″ (105.3cm × 23 × 35cm)
LOW FREQUENCY EXTENSION
27 Hz (DIN)
CROSSOVER
2nd-order electro-acoustic at 2.5 kHz (tweeter/mid) and 700Hz (mid/woofers)
FREQUENCY RESPONSE 30° OFF-AXIS
±3dB from 43 Hz – 20 kHz
SUITABLE AMPLIFIER POWER RANGE
15 – 250 watts
MAXIMUM INPUT POWER
180 watts
Specifications are subject to change without notice.
