Technics SL1500C

Technics Direct Drive Turntable System SL-1500C (Black or Silver)

UGS : SL1500C Catégorie : Marque:

Description

Technics SL1500C

Turntable section

Type
Direct Drive Manual Turntable
Turntable Speeds
33-1/3, 45 and 78 r/min
Starting Torque
0.18 N・m / 1.8 kg・cm (1.56 lbs-in)
Build-up Characteristics
0.7 s. from standstill to 33 1/3 rpm
Wow And Flutter
0.025 % W.R.M.S.
Turntable Platter
Aluminium diecast
Diameter : 332 mm (13-5/64 inch)
Weight : Approx. 2.0 kg (4.5 lbs) (Including Turntable Sheet)

Tonearm Section

Type
Universal Static Balance
Effective Length
230 mm (9-1/16″)
Overhang
15 mm (19/32″)
Tracking Error Angle
Within 2° 32’ (at the outer groove of 30 cm (12″) record)
Within 0° 32’ (at the inner groove of 30 cm (12″) record)
Offset Angle
22°
Arm-height Adjustment Range
0 – 6 mm
Stylus Pressure Adjustment Range
0 – 4 g (Direct Reading)
Head Shell Weight
Approx. 7.6 g
Applicable Cartridge Weight Range
(without auxiliary weight)
5.6 – 12.0 g
14.3 – 20.7 g (including head shell)
(with auxiliary weight)
10.0 – 16.4 g
18.7 – 25.1 g (including head shell)
Head Shell Terminal Lug
1.2 mmφ 4-pin terminal lug

Terminals

Audio Output
PHONO  (Pin Jack) x 1
EARTH TERMINAL x 1
LINE (Pin Jack) x 1

General

Power Supply
AC 120 V, 60 Hz
Power Consumption
8 W
Approx. 0.2W (Standby)
Dimensions (W x H x D)
453 x 169 x 372 mm
17-27/32 × 6-21/32 × 14-21/32 inch
Weight
Approx. 9.9 kg
Approx. 21.2 lbs
Accessories
Turntable, Turntable sheet, Dust cover, EP record adaptor, Balance weight, Auxiliary weight, Head shell, Cartridge(ortofon 2M Red), PHONO cable, PHONO earth lead, AC power supply cord, Owner’s Manual
