Description
DESIGN
2-driver, 2-way bass reflex bookshelf
FREQUENCY RESPONSE ON-AXIS
±3dB from 68 Hz – 25 kHz
HIGH FREQUENCY DRIVER
1” (25mm) X-PAL™ dome, ferro-fluid damped / cooled, Perforated Phase-Aligning Tweeter (PPA™) Lens
MID/BASS FREQUENCY DRIVER
5-1/2” (140mm) ART™ Surround with Carbon-Infused polypropylene cone. Perforated Phase-Aligning (PPA™) Lens
SENSITIVITY ROOM / ANECHOIC
90 dB / 87 dB
IMPEDANCE
Compatible with 8 ohms
FINISHES
Satin Black, Gloss White, Espresso Grain
WEIGHT
12.9 lbs. (5.85 kg)
DIMENSIONS HXWXD
11.125″ × 6.625 × 9.125″ (28.2cm × 16.9 × 23.9cm)
LOW FREQUENCY EXTENSION
50 Hz (DIN)
CROSSOVER
2nd-order electro-acoustic at 2.0 kHz (tweeter/mid)
FREQUENCY RESPONSE 30° OFF-AXIS
±3dB from 68 Hz – 20 kHz
SUITABLE AMPLIFIER POWER RANGE
15 – 130 watts
MAXIMUM INPUT POWER
70 watts
