Moon 260D

Description

Design features
  • Proprietary CD drive system mounted on our M-Quattro gel-based 4-point floating suspension for vibration damping, allowing ambient and spatial cues in your recordings to come to life like never before.
  • Two (2) digital outputs – S/PDIF and AES/EBU.
  • True 32-bit asynchronous Digital-to-Analog converter.
  • 4 digital inputs (S/PDIF x 2, TosLink x 1 and USB x 1) allowing for a connection to virtually any digital source.
  • USB input with galvanic isolation.
Specifications
  • Frequency response (full range)
    2Hz – 100kHz +0/-3dB
  • THD @ 1kHz, 0dBFS (A-weighted)
    0.005%
  • Intermodulation distortion
    0.005%
  • Dynamic Range
    120dB
  • Signal-to-noise Ratio
    120dB @ full output
  • Channel Separation
    116dB
  • Intrinsic Jitter
    1 picosecond RMS
  • Analog Output @ 0dBFS
    2.0 V
  • Analog output impedance
    75Ω
  • PCM Bit-depth range
    16 – 24 bits
  • PCM sampling frequency rates
    44.1 – 192kHz
  • Shipping weight
    16 lb / 7.5 kg
  • Dimensions (width x height x depth)
    16.9 x 3.4 x 13.1 in
  • 42.9 x 8.6 x 33.3 cm
