Description
Design features
- Balanced differential circuitry.
- Precision matched proprietary MOON Bipolar output transistors for improved bass response and accurate sonic reproduction.
- An oversized power supply using a custom proprietary toroidal transformer design.
- A high damping factor yielding superior musical dynamics, improved signal speed & refined timbre accuracy.
- “Class A” output to 5 watts for greater efficiency.
- Optimized selection of very high quality electronic components.
Specifications
-
Output Power at 8Ω125 W per channel
-
Output Power at 4Ω250 W per channel
-
Output Power – Bridged mono at 8Ω400 W
-
Input Sensitivity800mV RMS
-
Input Impedance47,500Ω
-
Gain31dB
-
Signal-to-noise Ratio100dB @ full power
-
Frequency response (full range)10Hz – 125kHz +0/-3dB
-
THD (20Hz – 20kHz @ 1 W)0.02%
-
THD (20Hz – 20kHz @ 125 W)0.05%
-
Intermodulation distortion0.02%
-
Shipping weight33 lb / 15 kg
-
Dimensions (width x height x depth)16.9 x 3.5 x 14.0 in
-
42.9 x 8.9 x 35.6 cm
