Description
DESIGN
3-driver, 2-way bass reflex, center channel
FREQUENCY RESPONSE ON-AXIS
±3dB from 65 Hz – 21 kHz
HIGH FREQUENCY DRIVER
1” (25mm) X-PAL™ dome, ferro-fluid damped / cooled, Perforated Phase-Aligning Tweeter (PPA™) Lens
MID/BASS FREQUENCY DRIVER
Two 5-1/2” (140mm) mineral-filled polypropylene cones / inverted dust cap / downroll surrounds
SENSITIVITY ROOM / ANECHOIC
93 dB / 90 dB
IMPEDANCE
Compatible with 8 ohms
FINISHES
Matte Black, Gloss White
WEIGHT
19 lbs. (8.6 kg)
DIMENSIONS HXWXD
7.25″ × 19.75 × 11.125″ (18.3cm × 50 × 28cm)
LOW FREQUENCY EXTENSION
53 Hz (DIN)
CROSSOVER
2nd-order electro-acoustic at 2.0 kHz
FREQUENCY RESPONSE 30° OFF-AXIS
±3dB from 64 Hz – 17 kHz
SUITABLE AMPLIFIER POWER RANGE
15 – 100 watts
MAXIMUM INPUT POWER
50 watts
