Description
DESIGN
2-driver, 2-way bass reflex bookshelf
FREQUENCY RESPONSE ON-AXIS
±3dB from 68 Hz – 25 kHz
HIGH FREQUENCY DRIVER
1” (25mm) X-PAL™ dome, ferro-fluid damped / cooled, Perforated Phase-Aligning Tweeter (PPA™) Lens
MID/BASS FREQUENCY DRIVER
6-1/2” (165mm) ART™ Surround with Carbon-Infused polypropylene cone. Perforated Phase-Aligning (PPA™) Lens
SENSITIVITY ROOM / ANECHOIC
90 dB / 87 dB
IMPEDANCE
Compatible with 8 ohms
FINISHES
Gloss Black, Gloss White
WEIGHT
18 lbs. (8.17 kg)
DIMENSIONS HXWXD
13.25″ × 7.875 × 12.375″ (33.5cm × 19.8 × 32.1cm)
LOW FREQUENCY EXTENSION
45 Hz (DIN)
CROSSOVER
2nd-order electro-acoustic at 2.0 kHz (tweeter/mid)
FREQUENCY RESPONSE 30° OFF-AXIS
±3dB from 68 Hz – 20 kHz
SUITABLE AMPLIFIER POWER RANGE
15 – 130 watts
MAXIMUM INPUT POWER
80 watts
Specifications are subject to change without notice.
