Description
System Format
3-way
Frequency Response (-6 dB)
35 Hz – 50 kHz
Sensitivity (1W@1M)
88 dB
Nominal Impedance
4 Ohms
Minimum Impedance
3.4 Ohms @ 1 kHz
Maximum SPL
114 dBA (Pair)
Power Handling (RMS)
200 W
Recommended Amplifier Requirements
80 – 200 W
Bass Alignment
Bass Reflex
Dual HiVe II port system
Crossover Frequency
L.F/ M.F: 650 Hz
M.F/ H.F: 3.5 kHz
Drive Unit Complement
2 x 61/2″ RDT II long-throw bass driver
1 x 21/2″ C-CAM mid-range driver
1 x MPD high-frequency transducer
External Dimensions (Including Grille and Terminals (H x W x D))
950 x 195 x 330.6 mm (373/8 x 711/16 x 13″)
External Dimensions (including Outrigger Feet and Spikes (H x W x D))
997 x 282.8 x 387.8 mm (391/4 x 111/8 x 151/4″)
Weight (each)
21.86 kg (48 lb 2 oz)
