Description
DESIGN
12″ (305 mm) Driver with ART™ Surround, 650W RMS (1300W Dynamic Peak), Class-D amplifier, App controlled via smartphone, Anthem Room Correction (ARC®) Included.
AMPLIFIER
1300 watts Dynamic Peak; 650 watts RMS
AMPLIFIER FEATURES
Auto-On / Off, improved soft-clipping circuitry
FREQUENCY RESPONSE ON-AXIS
±3 dB from 20Hz – 230Hz
ROOM CORRECTION
Anthem Room Correction (ARC®) Included
LOW FREQUENCY DRIVER
12″ (305 mm) ART™ Surround with carbon-loaded polypropylene cone
SENSITIVITY ROOM / ANECHOIC
100mV mono (max. volume) /
IMPEDANCE
RCA: 10k ohms
FINISHES
Satin Black
WEIGHT
62 lbs. (28.1 kg)
LOW FREQUENCY EXTENSION
15 Hz (DIN)
LOW PASS FILTER FREQUENCY
Variable 30Hz – 120Hz
SUB / SAT PHASE ALIGNMENT
Variable 0° – 180° App or Control Panel
INPUTS
Three RCA (Left, Right, and LFE) for left/right lineout and/or Sub-Out from receiver/processor or other line-level source, Two Speaker Level (Left and Right) for input from amplifier or other speaker level source, One Micro USB for ARC™ and firmware u
COMPATIBLE PRODUCTS
Defiance WT Wireless Kit (sold separately)
DIMENSIONS HXWXD (INCLUDES GRILLE).
19 7/16″ × 18″ × 19 7/16″ (49.3cm × 45.7cm × 49.4cm)
